Description

• Reads Camber from +9º to -9º, accurate to better than 1/4º
• Caster reads from +12º to -4º

• Glow-in-the-Dark vials - much easier to read even in good light
• CNC machined billet aluminum - polished, Bright Dip anodized, Laser etched
• NEW Super Magnetic Adapter - stronger pull - Now using twice as many premium 'Rare Earth' magnets (16 total) to hold to your hub better, CNC machined for a dead flat surface and the highest accuracy possible
• Can measure caster with or without turnplates (still best accuracy if used with turnplates)
• Includes hard case

Specifications
Caster Camber Gauge
	Material:	Billet Aluminum
	Finish:	Red anodized
	Camber Increments:	1/4°
	Positive Camber Adjustments:	0 to +9°
	Negative Camber Adjustments:	0 to -9°
	Caster Increments:	1/2°
	Positive Caster Adjustments:	0 to +12°
	Negative Caster Adjustments:	0 to -4°
	Bubble Level Included:	Yes
	Adapter Included:	Yes
	Case Included:	Yes
	Bolt Size:	5/16"-18
Adapter
	Style:	Magnetic
	Material:	Billet Aluminum
	Finish:	Black anodized
	Adapter Diameter:	3.0"
	Center Hole Diameter:	1.5"
	Center Hole Depth:	1.0"
